FEATURES
1.Corona discharge technology with quartz glass tube.
2.Unique air-cooled and water cooled system, long service life.
3.High conversion efficiency, low energy consumption.
4.Adjustable ozone output 0-100%.
5.High grade stainless steel cabinet.
6.Built-in air compressor, high pressure ozone output, plug and play.
Product Paramenters
| Ozone output | 30 G/Hr |
| Power | 520 W |
| Pressure(outlet) | 0.035Mpa |
| Cooling method | Air cooled+Water cooled |
| Outlet diameter | 8 mm |
| Unit weight | 14.6 kg |
| Disinfection area | 0-300 m² |
| Feed gas | clean and dry air (inner air pump) |
| Voltage | 110V/60Hz;220-240V/50Hz;220V/60Hz |
